MODULE-LEVEL POWER ELECTRONICS

Monitor, protect, and boost generation at the module level

Attached to every solar module, Conalog MLPE delivers panel-level real-time monitoring, rapid shutdown (RSD), and yield improvement in a single device.

Panel-Level Monitoring Solution (PATCH) Spec Sheet (PDF)

CORE FUNCTIONS

Get three benefits at once with MLPE

Per-Module Monitoring

Detect generation and faults in real time for each panel. See instantly which module has dropped.

Rapid Shutdown · RSD

Module-level Rapid Shutdown cuts power instantly during fires or inspections, keeping the site safe.

Yield Improvement

Reduce module terminal losses and track the optimal point with MPPT to raise generation.

SPECIFICATIONS

Detailed Spec Comparison

	2 in 1 GARD	2 in 1 BSTR	1 in 1 BSTR
Functions Provided
Per-Module Monitoring
Rapid Shutdown (RSD)
Yield Improvement
Mechanical Characteristics
Model Name	CA-GARD01-KR05D / KR10D	CA-BSTR01D	CA-BSTR01S
Module Attachment Type	1 per 2 modules	1 per 2 modules	1 per module
Product Size (W×L×H) Excluding cable	147 × 76 × 30mm	193 × 91 × 30mm	160 × 90 × 30mm
Weight Including cable · ±5%	698 g	805 g	714 g
Electrical Characteristics
Max System Voltage	1,500 VDC	1,000 VDC	1,500 VDC
Max Input Power	700 W × 2	500 W × 2	700 W
Max Input Current	20 A	13.5 A	17 A
Max Input Voltage	60 VDC	55 × 2 VDC	60 VDC
Max / Weighted Efficiency	98.0%	99.0% / 97.0%	98.0% / 97.0%
MPPT Operating Range	Not Supported	20–110 VDC · 0.5–12.5 A	15–55 VDC · 0.5–16 A
Certification
Certification	KC, JMIC	KC	KC, JMIC

2 in 1 GARD

Functions Provided

Per-Module Monitoring

Rapid Shutdown (RSD)

Yield Improvement

Mechanical Characteristics

Model Name CA-GARD01-KR05D / KR10D

Module Attachment Type 1 per 2 modules

Product Size (W×L×H) 147 × 76 × 30mm

Weight 698 g

Electrical Characteristics

Max System Voltage 1,500 VDC

Max Input Power 700 W × 2

Max Input Current 20 A

Max Input Voltage 60 VDC

Max / Weighted Efficiency 98.0%

MPPT Operating Range Not Supported

Certification

Certification KC, JMIC

2 in 1 BSTR

Functions Provided

Per-Module Monitoring

Rapid Shutdown (RSD)

Yield Improvement

Mechanical Characteristics

Model Name CA-BSTR01D

Module Attachment Type 1 per 2 modules

Product Size (W×L×H) 193 × 91 × 30mm

Weight 805 g

Electrical Characteristics

Max System Voltage 1,000 VDC

Max Input Power 500 W × 2

Max Input Current 13.5 A

Max Input Voltage 55 × 2 VDC

Max / Weighted Efficiency 99.0% / 97.0%

MPPT Operating Range 20–110 VDC · 0.5–12.5 A

Certification

Certification KC

1 in 1 BSTR

Functions Provided

Per-Module Monitoring

Rapid Shutdown (RSD)

Yield Improvement

Mechanical Characteristics

Model Name CA-BSTR01S

Module Attachment Type 1 per module

Product Size (W×L×H) 160 × 90 × 30mm

Weight 714 g

Electrical Characteristics

Max System Voltage 1,500 VDC

Max Input Power 700 W

Max Input Current 17 A

Max Input Voltage 60 VDC

Max / Weighted Efficiency 98.0% / 97.0%

MPPT Operating Range 15–55 VDC · 0.5–16 A

Certification

Certification KC, JMIC

Common Specifications

Connector · Cable: MC4 / 4.0 Sq
Operating Temperature: −40 ~ 80°C
Waterproof · Dustproof: IP68
Communication Method: BLE 5 wireless Mesh · interoperable across products
Connections per Repeater: 300 per Edge repeater
Warranty: 8 years
